Secure Locking
Secure your RF connectors, adapters, and cable assemblies in harsh environments with this suite of carefully designed and selected RF interconnects. The presence of environmental shock and vibration can negatively affect RF performance by causing two mated connectors to become loose and, in some cases, disconnect. SV's products below are ideal for harsh environments, from Secure Locking product lines like Threaded SMPM and Quarterback® to popular product lines like Field Replaceable 2 and 4 Hole Connectors and Keyed SMA Cable Assemblies.
Designed with locking features, additional screws, and mating captivation, this suite of products is ideal when RF is used in applications like:
Launch conditions
Travel over rugged terrain
Space flight
Military / Avionics
Features / Benefits:
- Variety of options for additional mating security
- Custom mechanical features provide extra captivation during mating
- Variety of threaded and push-on interfaces
- Available through distribution
- DC - 67 GHz
Applications:
- Mil/Aero
- Commercial
- Space
- Power dividers and combiners
- Military
- Aerospace
- Transceiver Box
1.85 mm
| Impedance (Ω) | 50 |
| Frequency GHz | 65 GHz |
| Shielding Effectiveness | ≥ -100 dB |
| Dielectric withstanding Voltage | 500 VRMS |
| Mating Cycles | 500 |
| Mating Torque | 5 - 7 in - lbs |
| Inter-mate ability | 2.4mm |
| Temperature Rating | -65°C to +165°C |
| Corrosion (salt spray) | MIL-STD-202, Method 101, Condition B |
| Vibration | MIL-STD-202, Method 204, Condition D |
| Shock | MIL-STD-202, Method 213, Condition I |
| Thermal Shock | MIL-STD-202, Method 107, Condition B |
| Moisture Resistance | MIL-STD-202, Method 106, Less Step 7B |
| Barometric Pressure (Altitude) | MIL-STD-202, Method 105, Condition C, 70k Ft. |
2.4 mm
| Impedance (Ω) | 50 |
| Frequency GHz | 50 GHz |
| Shielding Effectiveness | ≥ -100 dB |
| Dielectric withstanding Voltage | 500 VRMS |
| Mating Cycles | 500 |
| Mating Torque | 5 - 7 in - lbs |
| Inter-mate ability | 1.85mm |
| Temperature Rating | -65°C to +165°C |
| Corrosion (salt spray) | MIL-STD-202, Method 101, Condition B |
| Vibration | MIL-STD-202, Method 204, Condition D |
| Shock | MIL-STD-202, Method 213, Condition I |
| Thermal Shock | MIL-STD-202, Method 107, Condition B |
| Moisture Resistance | MIL-STD-202, Method 106, Less Step 7B |
| Barometric Pressure (Altitude) | MIL-STD-202, Method 105, Condition C, 70k Ft. |
2.92 mm
| Impedance (Ω) | 50 |
| Frequency GHz | 40 GHz |
| Shielding Effectiveness | ≥ -100 dB |
| Dielectric withstanding Voltage | 750 VRMS |
| Mating Cycles | 500 |
| Mating Torque | 7 - 10 in - lbs |
| Inter-mate ability | SMA |
| Temperature Rating | -65°C to +165°C |
| Corrosion (salt spray) | MIL-STD-202, Method 101, Condition B |
| Vibration | MIL-STD-202, Method 204, Condition D |
| Shock | MIL-STD-202, Method 213, Condition I |
| Thermal Shock | MIL-STD-202, Method 107, Condition B |
| Moisture Resistance | MIL-STD-202, Method 106, Less Step 7B |
| Barometric Pressure (Altitude) | MIL-STD-202, Method 105, Condition C, 70k Ft. |
SMA
| Impedance (Ω) | 50 |
| Frequency GHz | 18 GHz (select models to 26.5 GHz) |
| Shielding Effectiveness | ≥ -90 dB |
| Dielectric withstanding Voltage | 1000 VRMS |
| Mating Cycles | 500 |
| Mating Torque | 7 - 10 in - lbs |
| Inter-mate ability | 2.92mm |
| Temperature Rating | -65°C to +165°C |
| Corrosion (salt spray) | MIL-STD-202, Method 101, Condition B |
| Vibration | MIL-STD-202, Method 204, Condition D |
| Shock | MIL-STD-202, Method 213, Condition I |
| Thermal Shock | MIL-STD-202, Method 107, Condition B |
| Moisture Resistance | MIL-STD-202, Method 106, Less Step 7B |
| Barometric Pressure (Altitude) | MIL-STD-202, Method 105, Condition C, 70k Ft. |
SMP
| Impedance (Ω) | 50 |
| Frequency GHz | 40 GHz |
| Shielding Effectiveness | ≥ -80 dB DC - 3 GHz ≥ -65 dB 3 - 26.5 GHz |
| Dielectric withstanding Voltage | 500 VRMS |
| Mating Cycles - SB | 1000 |
| Mating Cycles - LD | 500 |
| Mating Cycles - FD | 100 |
| Insertion Force - SB | 3.0 lbs |
| Insertion Force - LD | 5.0 lbs |
| Insertion Force - FD | 7.0 lbs |
| Withdrawal Force - SB | 0.5 lbs |
| Withdrawal Force - LD | 7.0 lbs |
| Withdrawal Force - FD | 9.0 lbs |
| Axial Misalignment | .010” Max |
| Radial Misalignment | 3° Max |
| Temperature Rating | -65°C to +165°C |
| Corrosion (salt spray) | MIL-STD-202, Method 101, Condition B |
| Vibration | MIL-STD-202, Method 204, Condition D |
| Shock | MIL-STD-202, Method 213, Condition I |
| Thermal Shock | MIL-STD-202, Method 107, Condition B |
| Moisture Resistance | MIL-STD-202, Method 106, Less Step 7B |
| Barometric Pressure (Altitude) | MIL-STD-202, Method 105, Condition C, 70k Ft. |
SMPM
| Impedance (Ω) | 50 |
| Frequency GHz | 65 GHz |
| Shielding Effectiveness | ≥ -80 dB DC - 3 GHz ≥ -65 dB 3 - 26.5 GHz |
| Dielectric withstanding Voltage | 325 VRMS |
| Mating Cycles - SB | 500 |
| Mating Cycles - FD | 100 |
| Insertion Force - SB | 2.5 lbs |
| Insertion Force - FD | 4.5 lbs |
| Withdrawal Force - SB | 1.5 lbs |
| Withdrawal Force - FD | 6.5 lbs |
| Axial Misalignment | .010” Max |
| Radial Misalignment | 3° Max |
| Temperature Rating | -65°C to +165°C |
| Corrosion (salt spray) | MIL-STD-202, Method 101, Condition B |
| Vibration | MIL-STD-202, Method 204, Condition D |
| Shock | MIL-STD-202, Method 213, Condition I |
| Thermal Shock | MIL-STD-202, Method 107, Condition B |
| Moisture Resistance | MIL-STD-202, Method 106, Less Step 7B |
| Barometric Pressure (Altitude) | MIL-STD-202, Method 105, Condition C, 70k Ft. |
SMPS
| Impedance (Ω) | 50 |
| Frequency GHz | 65 GHz |
| Shielding Effectiveness | ≥ -80 dB DC - 3 GHz ≥ -65 dB 3 - 26.5 GHz |
| Dielectric withstanding Voltage | 250 VRMS |
| Mating Cycles - SB | 500 |
| Mating Cycles - FD | 100 |
| Insertion Force - SB | 1.2 lbs |
| Insertion Force - FD | 2.5 lbs |
| Withdrawal Force - SB | 1.0 lbs |
| Withdrawal Force - FD | 4.5 lbs |
| Axial Misalignment | .010” Max |
| Radial Misalignment | 3° Max |
| Temperature Rating | -65°C to +165°C |
| Corrosion (salt spray) | MIL-STD-202, Method 101, Condition B |
| Vibration | MIL-STD-202, Method 204, Condition D |
| Shock | MIL-STD-202, Method 213, Condition I |
| Thermal Shock | MIL-STD-202, Method 107, Condition B |
| Moisture Resistance | MIL-STD-202, Method 106, Less Step 7B |
| Barometric Pressure (Altitude) | MIL-STD-202, Method 105, Condition C, 70k Ft. |
Part # 3321-60054
1.85mm Female Field Replaceable Flange Mount Connector, 2 Hole (Accepts Ø.009 Pin)
Available Inventory: 93
3321-60054
1.85mm Connectors 3321-60054
Part # 3321-60055
1.85mm Female Field Replaceable Flange Mount Connector, 4 Hole (Accepts Ø.009 Pin)
Available Inventory: 80
3321-60055
1.85mm Connectors 3321-60055
Part # 1621-60071
2.4mm Female Field Replaceable Flange Mount Connector, 2 Hole (Accepts Ø.012 Pin)
Available Inventory: 94
1621-60071
2.4mm Connectors 1621-60071
Part # 1621-60072
2.4mm Female Field Replaceable Flange Mount Connector, 4 Hole (Accepts Ø.012 Pin)
Available Inventory: 74
1621-60072
2.4mm Connectors 1621-60072
Part # 1521-60193
2.92mm Female Field Replaceable Flange Mount Connector, 2 Hole (Accepts Ø.012 Pin)
Available Inventory: 94
1521-60193
2.92mm Connectors 1521-60193
Part # 1521-60187
2.92mm Female Field Replaceable Flange Mount Connector, 2 Hole (Accepts Ø.015 Pin)
Available Inventory: 120
1521-60187
2.92mm Connectors 1521-60187
Part # 1521-60194
2.92mm Female Field Replaceable Flange Mount Connector, 4 Hole (Accepts Ø.012 Pin)
Available Inventory: 104
1521-60194
2.92mm Connectors 1521-60194
Part # 1521-60188
2.92mm Female Field Replaceable Flange Mount Connector, 4 Hole (Accepts Ø.015 Pin)
Available Inventory: 34
1521-60188
2.92mm Connectors 1521-60188
SF1112-6144
2.92mm Adapters SF1112-6144
Part # 1115-6124
2.92mm Female to SMP Male, FD, Flange Mount Adapter, 2 Hole, with Screws
Available Inventory: 76
1115-6124
2.92mm Adapters 1115-6124
Part # 1115-6125
2.92mm Female to SMP Male, SB, Flange Mount Adapter, 2 Hole, with Screws
Available Inventory: 224
1115-6125
2.92mm Adapters 1115-6125
1115-6088
2.92mm Adapters 1115-6088
SF1132-6078
2.92mm Adapters SF1132-6078
Part # 1115-6126
2.92mm Female to SMPM Male, FD, Flange Mount Adapter, 2 Hole, with Screws
Available Inventory: 462
1115-6126
2.92mm Adapters 1115-6126
Part # 7029-3410
SMA Female Keyed (120°) Bulkhead to SMA Male 6" Cable Assembly for .085 Cable
Available Inventory: 50
7029-3410
SMA Cable Assemblies 7029-3410
Part # 7029-3409
SMA Female Keyed (150°) Bulkhead to SMA Male 6" Cable Assembly for .085 Cable
Available Inventory: 50
7029-3409
SMA Cable Assemblies 7029-3409
Part # 7029-3408
SMA Female Keyed (180°) Bulkhead to SMA Male 6" Cable Assembly for .085 Cable
Available Inventory: 50
7029-3408
SMA Cable Assemblies 7029-3408
Part # 7029-3411
SMA Female Keyed (90°) Bulkhead to SMA Male 6" Cable Assembly for .085 Cable
Available Inventory: 48
7029-3411
SMA Cable Assemblies 7029-3411
Part # 7029-3414
SMA Male Keyed (120°) to SMA Male 6" Cable Assembly for .085 Cable
Available Inventory: 84
7029-3414
SMA Cable Assemblies 7029-3414
Part # 7029-3413
SMA Male Keyed (150°) to SMA Male 6" Cable Assembly for .085 Cable
Available Inventory: 50
7029-3413
SMA Cable Assemblies 7029-3413
Part # 7029-3412
SMA Male Keyed (180°) to SMA Male 6" Cable Assembly for .085 Cable
Available Inventory: 151
7029-3412
SMA Cable Assemblies 7029-3412
7012-1084
SMP Cable Assemblies 7012-1084
7012-1085
SMP Cable Assemblies 7012-1085
1221-40051
SMP Connectors 1221-40051
1221-40049
SMP Connectors 1221-40049
1221-40050
SMP Connectors 1221-40050
1222-60007
SMP Connectors 1222-60007
1222-60008
SMP Connectors 1222-60008
1115-6083
SMP Adapters 1115-6083
1112-4018
SMP Adapters 1112-4018
1112-6114
SMP Adapters 1112-6114
7032-8547
SMPM Cable Assemblies 7032-8547
7032-8544
SMPM Cable Assemblies 7032-8544
7032-8548
SMPM Cable Assemblies 7032-8548
7032-8545
SMPM Cable Assemblies 7032-8545
Part # 7032-9469
SMPM Male QB Bulkhead to SMA Male 12" Cable Assembly for .047 Cable
Available Inventory: 71
7032-9469
SMPM Cable Assemblies 7032-9468
Part # 7032-9468
SMPM Male QB Bulkhead to SMA Male 6" Cable Assembly for .047 Cable
Available Inventory: 62
7032-9468
SMPM Cable Assemblies 7032-9468
3821-60008
SMPS Connectors 3821-60008
7038-0741
SMPS Cable Assemblies 7038-0741
3221-60017
SMPM Connectors 3221-60017
3221-60016
SMPM Connectors 3221-60016
3222-40060
SMPM Connectors 3222-40060
3222-40059
SMPM Connectors 3222-40059
1132-6108
SMPM Adapters 1132-6108
Part # 3211-40170
Threaded SMPM Male PCB Edge Launch Connector (Pre-Tinned), SB
Available Inventory: 151
3211-40170
SMPM Connectors 3211-40170
3211-40121
SMPM Connectors 3211-40121
Part # 3212-60037
Threaded SMPM Male PCB Thru-Hole Connector (Pre-Tinned), R/A, SB
Available Inventory: 223
3212-60037
SMPM Connectors 3212-60037
3211-60298
SMPM Connectors 3211-60298
Part # 3211-60407-1S
Threaded SMPM Male Solderless PCB Edge Launch Connector, 2 Hole, with 4.76mm Screws, SB
Available Inventory: 142
3211-60407-1S
SMPM Connectors 3211-60407-1S
Part # 3211-60407-2S
Threaded SMPM Male Solderless PCB Edge Launch Connector, 2 Hole, with 6.35mm Screws, SB
Available Inventory: 115
3211-60407-2S
SMPM Connectors 3211-60407-2S
