Attribute name | Attribute value |
---|---|
Gender | Plug (Male) |
Orientation (Body) | Straight |
Coupling | Push-on |
Finish | Gold |
RF Series | BMB |
Detent | Full Detent |
Mounting Type | PCB Edge Launch |
Electrical | |
Impedance | 50 ohms |
Frequency | 22 GHz |
Shielding Effectiveness | ≥ -90 dB |
Dielectric withstanding Voltage | 1500 VRMS |
Mechanical | |
Mating Cycles | 500 |
Insertion Force | 2.0 lbs |
Withdrawal Force | 6 oz |
Environmental | |
Temperature Rating | -65°C to +165°C |
Corrosion (salt spray) | MIL-STD-202, Method 101, Condition B |
Thermal Shock | MIL-STD-202, Method 107, Condition B |
Shock | MIL-STD-202, Method 213, Condition I |
Vibration | MIL-STD-202, Method 204, Condition D |
Barometric Pressure (Altitude) | MIL-STD-202, Method 105, Condition C, 70k Ft. |
Moisture Resistance | MIL-STD-202, Method 106, Less Step 7B |
