SMPM Male VITA 67.3 Plug-In Contact (75 Ohm) for 1672A Cable
P/N: 7511-60002

In stock at Qty Order
Mouser Electronics 25
Newark 25
Farnell 25
Products specifications
Attribute name Attribute value
Family VITA 67
RF Series VITA SMPM
Orientation (Body) Straight
Gender Plug (Male)
Coupling Push-on
Detent Smooth Bore
Mounting Type Snap-in
Termination Style Solder
Number of Ports Single
Finish Passivated
Cable Type 1672A
Electrical
Impedance 75 ohms
Frequency 18 GHz
Dielectric withstanding Voltage 325 VRMS
Shielding Effectiveness ≥ -100 dB, DC to 26.5 GHz
Mechanical
Mating Cycles 500
Insertion Force 2.5 lbs (per contact)
Withdrawal Force 1.5 lbs
Environmental
Temperature Rating -65°C to +165°C
Shock MIL-STD-202, Method 213, Condition I
Vibration MIL-STD-202, Method 204, Condition D
Corrosion (salt spray) MIL-STD-202, Method 101, Condition B
Moisture Resistance MIL-STD-202, Method 106, Less Step 7B
Thermal Shock MIL-STD-202, Method 107, Condition B
Barometric Pressure (Altitude) MIL-STD-202, Method 105, Condition C, 70k Ft.
Spinning Wheel; Your Submission is Loading

Contact Us

How can we help?

*
*
*
*
*
*
*
*
Products specifications
Attribute name Attribute value
Family VITA 67
RF Series VITA SMPM
Orientation (Body) Straight
Gender Plug (Male)
Coupling Push-on
Detent Smooth Bore
Mounting Type Snap-in
Termination Style Solder
Number of Ports Single
Finish Passivated
Cable Type 1672A
Electrical
Impedance 75 ohms
Frequency 18 GHz
Dielectric withstanding Voltage 325 VRMS
Shielding Effectiveness ≥ -100 dB, DC to 26.5 GHz
Mechanical
Mating Cycles 500
Insertion Force 2.5 lbs (per contact)
Withdrawal Force 1.5 lbs
Environmental
Temperature Rating -65°C to +165°C
Shock MIL-STD-202, Method 213, Condition I
Vibration MIL-STD-202, Method 204, Condition D
Corrosion (salt spray) MIL-STD-202, Method 101, Condition B
Moisture Resistance MIL-STD-202, Method 106, Less Step 7B
Thermal Shock MIL-STD-202, Method 107, Condition B
Barometric Pressure (Altitude) MIL-STD-202, Method 105, Condition C, 70k Ft.
Customers Also Viewed
Part #   7032-7840

SMPM Male VITA 67.3 to SMA Male 12" Cable Assembly for .085 Cable

Available Inventory: 78
7032-7840
VITA Cable Assemblies 7032-7840
Datasheet
Part #   7032-7841

SMPM Male VITA 67.3 to SMA Male 12" Cable Assembly for .047 Cable

Available Inventory: 22
7032-7841
VITA Cable Assemblies 7032-7841
Datasheet
Part #   3211-60350

SMPM Male VITA 67.3 Plug-In Contact for .085 Cable
